2. GENERAL DESCRIPTION
TheTS-801andTS-901Chairmanunits,andtheTS-802andTS-902Delegateunitsaredesigned
for use in the TOA infrared conference systems.
These units provide wireless communication via the Infrared Transmitter/Receiver unit
connected to the Central unit.
TwotypesofdedicatedmicrophonesaremadeavailablefortheChairmanandDelegateunitsas
optionalproducts:theTS-903standardtypeandtheTS-904longtype.
3. FEATURES
•Since the Chairman units and the Delegate units require no wiring, they permit easy
installation based on a free layout.
•Upto192TS-801/802/901/902unitsandTS-911/912wiredconferenceunitsconnectabletothe
TS-910.
•Upto96TS-901andTS-902unitsconnectabletotheTS-900.
•Upto64TS-801andTS-802unitsconnectabletotheTS-800.
•
BothTS-901andTS-902 units equipped with Voting and base/translation language selection
functions and
TS-801andTS-802 units designed primarily for speaking and monitoring can be
freely used. In the case of the
TS-801andTS-802 units, they can monitor the base language
only.
•PrioritySpeechkeytotakeprecedenceoverDelegateunits.
•Statusafterpriorityspeech,PriorityChimeON/OFFfunction,andpriorityspeechkeyoperation
mode settable by a DIP switch.
•TheTS-901isequippedwithavotingfunctionenabledbytheDIPswitchsetting.
•Chairman and Delegate unitsmicrophonesareattachedviaXLRconnectorsthatpermiteasy
detachmentformorespace-savingconvenienceinstorage.
•Two types of
Chairman and Delegate units microphones are made available and freely
interchangeable:StandardtypeandLongtype.
URL:http://www.toa.jp/
133-02-00174-01
5. SPECIFICATION
ModelNo. TS-801 TS-802 TS-901 TS-902
PowerSource  7.4VDC(battery),9VDC(ACadapter)
(suppliedfromtheoptionalBP-900batteryorAD-0910ACadapter)
Current Consumption Max.270mA
Infrared Emitter/Detector
Wavelength 870nm(AM:Brightnessmodulation)
Modulation Method Frequencymodulation
CarrierFrequency Transmission:
 Audiochannel1: 7.35MHz
 Audiochannel2: 8.10MHz
 Audiochannel3: 8.55MHz
 Audiochannel4: 9.15MHz
 Controlchannel: 6.45MHz
Reception:
 Audiochannel: 1.95MHz
Transmission:
 Audiochannel1: 7.35MHz
 Audiochannel2: 8.10MHz
 Audiochannel3: 8.55MHz
 Audiochannel4: 9.15MHz
 Controlchannel: 6.45MHz
Reception:
 Baselanguagechannel: 1.95MHz
Translation language channel: 2.25MHz
Acceptance Angle Vertical:90°,Horizontal:120°
Emission Angle Vertical:90°,Horizontal:120°
CoveringRange 7mor22.97ft(radius)
Input Microphoneterminal:XLR-4-31 type (dedicated for connecting the optional
TS-903orTS-904)
Output  Monitorspeaker: 8Ω,0.2W
 Headphone: ø3.5mmminijack(3P:monaural)x2
LED Indicator
Speechindicator(asheswhentheunitisoutofcommunicationsrange),
Powerindicator(asheswhentheunitisoutofcommunicationsrangeor
whenthebatterylevelislow)
-
Votingstatusindicators1–3
BatteryLife Approx.10hours(whenthefully-chargedBP-900batteryisusedwith"During
speech"to"Standby"ratioof1:2)
Function Monitorvolumecontrol,Headphonevolumecontrol
Priority speech function
- Priority speech function -
-
Voting function
Monitorselectorswitch(MAIN/SUB)
Operating Temperature 0to40ºC(32to104ºF)
OperatingHumidity 90%RHorless(nocondensation)
Finish TopPanel:ABSresin,graymetallic,paint,semi-gloss
Dimensions 210(w)x68.6(h)x152(d)mm(8.27"x2.7"x5.98")
Weight 630g(1.39lb) 640g(1.41lb)
Note:Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Optional products
Microphone: TS-903,TS-904(Selecteitherone.)
Lithium-ionbattery:BP-900
ACadapter: AD-0910
Traceability Information for Europe
Manufacturer:
TOA Corporation
7-2-1,Minatojima-Nakamachi,Chuo-ku,Kobe,Hyogo,
Japan
Authorizedrepresentative:
TOAElectronicsEuropeGmbH
Suederstrasse282,20537Hamburg,
Germany
This is a class A product.
Inadomesticenvironmentthisproductmaycauseradiointerferenceinwhichcasethe
user may be required to take adequate measures.
