Pro Fusion User Manual v.2.2 20
7. If it is not yet connected, plug in the eye tracker’s USB cable to the correct USB port in your
computer.
The included USB Type-A to Type-C adapter and the eye tracker AC power adapter
must be used if the computer does not have a USB Type-C port. For more information,
read How to use the USB Type-A to Type-C adapter.
8. Move to the next step.
5.4 Display setup in Tobii Pro Eye Tracker Manager
Now the algorithms on the eye tracker need to understand where the eye tracker is in relation to the
screen and map the gaze points accordingly.
1. Open Pro Eye Tracker Manager if it’s not already running, and select your eye tracker.
2. On the Overview tab, locate Display Setup and click the ellipsis icon to the right. On the drop-
down menu, click New.
3. Select Regular setup and click the Next button.
4. If multiple screens are used, select the screen that has the Pro Fusion attached to its bezel.
5. Enter the position of the eye tracker in relation to the screen. Use the radio buttons to select
whether the eye tracker is positioned under or over the screen and enter the measurement in
millimeters.
6. Align the dotted orange lines on the screen with the two outer white marks on the top of your
Pro Fusion.
7. Save your display by naming the setup and clicking the Save button.
8. To confirm that Pro Fusion can detect your eyes, enable the Position Guide at the bottom left
of Pro Eye Tracker Manager. Once activated, you should be able to see two “eyes” in a face
contour.
9. Move to the next step. In the next section, you will test your setup by performing a calibration.
For more information, read Calibration.
You can always return to Pro Eye Tracker Manager and use it when you change com-
puters or screens or want to recalibrate.
5.5 Calibration
When you are done configuring your eye tracker, you should run a calibration to test to see if the eye
tracker is mapping the gaze points correctly to your display.
How to test your eye tracking setup in Pro Eye Tracker Manager:
1. Make sure the eye tracker is attached to the screen bezel and connected to your computer.
Open Pro Eye Tracker Manager. For more information, read Tobii Pro Eye Tracker
Manager.
