Trained personnel should check that the unit has been pre-delivered in accordance with the relevant To h a ts u
Outboard Manual. The following points must be confirmed at pre-delivery and during the water test.
Ref No:
MODEL PRIMARY ID (Port) PRIMARY ID (Starboard) HULL ID NUMBER (HIN)
BOAT MAKER/MODEL IGNITION KEY NUMBER (Port) IGNITION KEY NUMBER (Starboard)
TRAILER NUMBER
CHECK BEFORE OPERATION CHECK DURING OPERATION
All Standard Items Supplied (Defect, Breakage, Missing parts)
Engine Mounting (High, Width, Proper hardware, Secured)
Harness and hoses installation (Secured and Properly Dressed)
Main Wire Harness installation Extended ft No Extended
Multifunction Gage Dip Switch Setting for Application
Instrument Operation/Connections
Tiller Handle Installation/Secure
Remote Control Operation/Adjustments Type:
Cable Stroke and Routing Length: m Min. radius: cm
Shift Throttle Operation
Cable Stroke and Routing Length: m Min. radius: cm
Mechanical Steering Operation/Installation Maker:
Hydraulic Steering Operation/Bleed Maker:
Primer Pump Installed Properly (Arrow pointing up)
Fuel Line/Tank Installation/Connections Routing Sealed/Secured
Inner Diameter: m
Length: m Height: m
Boat Fuel Filter Type
Fuel Vacuum Test Result: kPa @ WOT rpm (over 50ps)
Battery Meets/Exceeds Engine Specifications Type:
Battery Charged/Secured/Connections Tight
Battery Cable Installation and Routing
Battery Cable Type:
Cable Length:
Battery S/W installation (Secured, Properly Connections)
Manual Tilt Operation
Power Trim/Tilt Operation
Lower Unit Oil Level
Overheat Warning System (Ground sensor lead on applicable models)
Visual Inspection of Engine
<2-Stroke Fuel and Oil Setup>
Break-In Premix Ratio (Except TLDI models) 25 : 1
Oil in Remote and Marine Engine Tank
To h a t s u TCW3 Equivalent Quality Oil Brand:
Breed Oil Injection Pump / No air oil Injection Lines
Electric Oil Pump Function
<4-Stroke Oil Setup>
Check Engine Oil Level (Ensure unit is not overfilled)
Engine Oil Classification:
Brand:
<Carburetion: 2 and 4-Stroke models>
Manual/Electric Choke Operation
Electric Starter Operation (Start in gear protection functions)
Manual/Electric Choke Operation
Neutral Switch function
Stop Switch/Emergency Switch Operation
Steering Operation
Throttle Operation/Friction Adjustment Neutral/Cruising
Proper Shift Cable Adjustment/Operation (F-N-R)
Cooling System Water Flow
Fuel/Oil/Water/Exhaust leaks
Oil Warning system Check (Equipped models)
Indicator Lamp and Buzzer
Oil and Temperature Warning functions (Equipped models)
Engine reaches operating temperature
Power Trim/Tilt Operation
Instrument Operation
Trim Tab Adjustment (retorque after operation)
Propeller Selection: Brand: To h a t s u Other:
Material:
SUS AL Plastic
Model:
Dia: Pitch:
Idle RPM Single/P: rpm S: rpm
In gear idle RPM Single/P: rpm S: rpm
Factory-recommended W.O.T. RPM Range: rpm
W.O.T. RPM Single/P: rpm S: rpm
No Cavitations/Ventilation
Remarks:
Inspector’s signature Date
Dealer name Phone number
Dealership address
CUSTOMER DELIVERY CHECKLIST
Operation of Equipment/Boat Accessories Explained
(Proper Trim and Tilt operation demonstrated)
Operation/Orientation Ride with Dealership Personnel
Warranty/Owner’s Manual and Keys Given to Customer by Dealer.
Customer Introduced to Service Manager/Writer
Return-to-Port Operations (Oil System, RPM Reduction)
Gauge Operation/Warning Symbols Explained
2-Stroke: Use of To h a t s u 2 stroke/TC-W3 or Equivalent Rated Oil
4-Stroke: Use of To h a t s u 4 stroke or Equivalent Rated Oil
4-Stroke: Show Customer Proper Checking Procedures and Proper Level of
Engine Oil
Engine Break-in Procedure Explained
Maintenance/Care Schedule Explained
Advised of First Scheduled Maintenance
Warranty Coverage Explained to Customer’s Satisfaction,
Including Customer Responsibilities
Customer questions answered by Dealership Personnel
Break-in Time Placed on Engine by Dealership Personnel
hours:
Minutes:
Customer name Phone number
Customer address
Customer signature Date
Date of Issue : / /2007 ORIGINAL TO BE HELD BY DEALER/COPY TO CUSTOMER
TOHATSU OUTBOARD MOTOR
Pre-Delivery Inspection Check List 2 and 4-Stroke Models
The above
materia
has been explained and/or provided to me by dealership
ersonne
.
My questions were answered and explained to my satisfaction.
