TOHATSU MFS 4 Service Manual

7-7
4st 4/5/6 2011
7
1 Bottom Cowl 1
2 Bottom Cowl (Integral Tank) 1
3 Hook Lever 1
4 Seal Ring Hook Lever 1
5 Hook Lever Bushing 1
6 Wave Washer d=14 1
7 Cover Hook 1
8 Bolt 1 M6 L=12mm
9 Washer 6-16-1.5 1
10 Grommet Starter Lock Rod 1
11 Grommet Throttle Lever 2
12 Grommet 18-2.5 1
13 Clamp 6.5-47.5P 1
14 Screw 1 M6 L=12mm
15 Grommet 17-2.7 1
16 Tiller Handle Sub-Ass'y 1
17 Tiller Handle 1
18 Stud 2
19 Grip 1
20 Throttle Shaft Damper 1
21 Bushing 14-15.8-7 1
22 Screw 1 M5 L=18mm
23 Throttle Shaft Support 1
24 Screw 1 M6 L=12mm
25 Friction Piece 1
26 Adjusting Screw 1
27 Washer 1
28 Nut 1 M6
29 Throttle Shaft 1
30 Throttle Decal 1
31 Plastic Rivet 6.5 1
32 Spacer Handle 1
33 Washer 30-45-1 1
34 Spring Washer 2
35 Throttle Wire 2
36 Protector
Wireharness
1
37 Bushing Steering 2
38 Steering Handle Stopper 1
39 Plastic Rivet 6.5 1
40 Nut 2 M6
41 Fuel Connector (Engine Male 1
42 Fuel Connector Protector 1
43 Fuel Hose 4.5L-75 1
44 Clip Fuel pipe 1
45 Screw 2 M4 L=10mm
46 Fuel Hose F 1
47 Clip Fuel pipe 1
48 Fuel Cock Ass'y 1
49 Grommet 2
50 Bolt 4 M6 L=16mm
51 Choke Rod 1
52 Choke Rod Bushing 1
53 Storage Decal 1
54 Label Oil Pressure 1
55 Spark Plug Decal 1
56 Fuel Lever Decal 1
57 Bolt 1 M6 L=40mm
58 Washer 1
Ref.
No.
Description RemarksQ'ty
