TOHATSU MFS 4 Service Manual

3-14
Maintenance
4st 4/5/6 2011
5. Hold pivot and loosen lock nut.
33
Valve Clearance (when engine is cold) :
(IN) intake side : 0.06 - 0.14mm (0.0025 - 0.0055in)
(EX) exhaust side : 0.11 - 0.19mm (0.0045 - 0.0075in)
7. Rotate pivot to adjust valve clearance, and then, tighten lock
nut.
6. Put thickness gauge 3 in the gap between rocker arm and
valve.
8. Check valve clearance again.
Pivot Adjust Nut :
10 N
· m (7 lb · ft) [1.0 kgf · m]
MFS4-5-6Ech03110422.qxd 11.4.22 5:45 PM  ページ14
