TOHATSU MFS 4 Service Manual

4
4-7
4st 4/5/6 2011
1 Fuel Hose C 1
2 Fuel Hose Protector 1
3 Fuel Tank 1
4 Hose 1 98AB-501000
5 Clip Fuel pipe 2
6 Fuel Tank Holding Plate 1
7 Mount Motor Cover Lower 4
8 Rubber Mount 9-23-4 1
9 Spacer 6.2-9-15.7 2
10 Spacer 6.2-9-11.5 1
11 Washer 6.5-21-1 4
12 Bolt 2 M6 L=25mm
13 Nut 1 M6
14 Bolt 1 M6 L=20mm
15 Bracket (Rear) 1
16 Fuel Tank Cap Ass'y 1
17 Tank Filler Cap Gasket 1
18 Fuel Tank Seal 1
19 Clamp 6.5-47.5P 2
20 Screw 1 M5 L=10mm
21 Washer 1
22 Clamp 6.5-14 1
23 Fuel Hose 4.5S-310 1
24 Hose 1
25 Fuel Hose 4.5L-20 1
26 Fuel Hose 4.5L-115 1
27 Band 158 2
28 Pipe Joint 1
29 Non-Return Valve 1
30 Clip Fuel pipe 12
31 Screw 1 M6 L=12mm
Ref.
No.
Description RemarksQ'ty
Do not reuse.
