5
5-5
4st 4/5/6 2011
1-1 Flywheel MF54 (Mark48) 1
1-2 Flywheel MF54 (Mark50) 1 "for Sail Pro (with Alternater)"
2 Alternator Ass'y 1
3 Screw 4 M5 L=25mm
4Washer 4
5 Clamp 1
6 Screw 1 M4 L=8mm
7Washer 1
8 Nut 12-P1.25 1
9 Igniter W/R-Cap 1
10 Plug Cap W/Resistance 1
11 Bolt 2 M6 L=30mm
12-1 Clamp 6.5-67P 2
12-2 Clamp 6.5-47.5P 1
13 Screw 1 M6 L=12mm
14 Rectifier Complete 1
15 Fuse (10A) 1
16 Clamp 7-80P 1
17 Battery Cable 1
18 Cable Terminal Plug 1
19 Grommet 17-3 1
20 Pilot Lamp Ass'y 1
21 Stop Switch Ass'y 1
22 Stop Switch Lanyard Ass'y 1
23 Clamp 6.5-14 1
24 Bolt with Washer 1 M6 L=12mm
25-1 Protector Wireharness 1 For Separate Tank Model
25-2 Protector Wireharness 1 For Integral Tank Model
Ref.
No.
Description RemarksQ'ty
MFS4-5-6Ech05110425.qxd11.4.2511:39AM ページ5
To Next Page
