TOHATSU MFS 4 Service Manual

5
5-9
4st 4/5/6 2011
1 Cylinder Head Ass'y 1
2 Intake Valve 1
3 Exhaust Valve 1
4 Valve Spring Seat 2
5 Valve Spring 2
6 Retainer 2
7 Cotter 4
8 Dowel Pin 6-12 2
9 Cylinder Head Gasket 1
10 Cylinder Head Bolt 2
11 Cylinder Head Bolt 2
12 Exhaust Cover Gasket 1
13 Cylinder Head Cover 1
14 Cylinder Head Cover Gasket 1
15 Bolt 4 M6 L=16mm
16 Washer 6-16-1.5 4
17 Thermostat 1
18 Thermostat Cap 1
19 Thermostat Cap Gasket 1
20 Camshaft Ass'y (F6A) 1
21 Lifter 2
22 Push Rod 2
23 Plate Push Rod 1
24 Pivot Bolt 2
25 Rocker Arm 2
26 Pivot Rocker Arm 2
27 Adjusting Nut 2
28 Throttle Drum 1
29 Throttle Opener 1
30 Collar Drum 1
31 Bolt 1 M6 L=35mm
32 Washer 6-16-1.5 1
33 Bolt 2 M6 L=45mm
34 Throttle Rod 1
35 Spark Plug (DCPR6E) 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
