ENGINE OPERATION42
7
1. ON
2. START
3. OFF
ENON00035-A
Note
The free throttle lever can not be raised
when the control lever shift is in Forward
or Reverse.
6. Check the cooling water from cooling
water check port.
ENOM00974-A
Top mount RC type
1. Be sure to install the stop switch lock
to the stop switch, and attach the
stop switch lanyard securely to the
operator or to the operator's PFD
(Personal Flotation Device.)
1. Stop switch lock
2. Insert the main switch key.
3. Set the control lever in the Neutral
position. Do not use the Neutral
throttle button to open the throttle
when starting the engine.
1. Forward (F)
2. Neutral (N)
3. Reverse (R)
4. Fully opened (Forward)
5. Fully opened (Reverse)
6. Neutral throttle button
7. Control lever
8. Neutral lock arm
ENOF00868-0
1
ENOF02409-0
N
R
F
1
7
4
8
5
6
7
2
3
R
F
N
ENOF00937-0
To Next Page
