ENGINE OPERATION 35
7
(For electrical starter type)
4. Push the starter switch button and
release the button when the engine
has started.
1. Starter button
5. Check the cooling water from cooling
water check port.
Side mount RC type
1. Be sure to install the stop switch lock
to the stop switch, and attach the
stop switch lanyard securely to the
operator or to the operator's PFD
(Personal Flotation Device.)
1. Stop switch lock
2. Insert the main switch key.
3. Set the control lever in the Neutral
position.
ENON00504-1
Note
The free accel lever can not be raised
when the control lever is in Forward or
Reverse.
1. Neutral (N)
2. Control lever
3. Fully opened (Forward)
4. Fully opened (Reverse)
5. Free throttle lever
6. Main switch key
7. Stop switch
4. Turns the main switch key to START
position.
1. ON
2. START
3. OFF
N
R
F
1
2
3
4
5
6
7
ENOF00870-1
1
2
3
ENOF00871-1
