18
Select
Before Setting
After Setting
⑤ Other settings
Use ▲▼ key to set the memory counter to 00 (RUN
measuring mode).
Keep MD key pressed for more than 2 seconds till it
the display changes.
●Selecting setting subject
Select MODE_S （setting on tightening mode and
torque setting), or PARA_S (other parameter settings）.
Use ▲▼ key to select PARA_S and press MEM key to
save and proceed to the next.
(Press MD key to proceed without saving. Press C key
to return to RUN measuring mode).
●Setting measurement unit (Default: N
・
m)
Select the torque unit
（N
･
m ／ kgf
･
cm ／ kgf
･
m ／ lbf
･
in ／ lbf
･
ft）
The measured torque and the set torque will be
converted into the selected torque unit.
Use ▲▼key to select the torque unit and press MEM
key to save and proceed to the next.
(If you press MD key, it proceeds without saving. If you
press C key, it returns to RUN measurement mode).
●Setting Auto memory/Reset timer (Default: 0.0)
Set Auto memory/Reset t imer. After ti ghtening
completion, the auto memory function saves the data
automatically after the set timing, and proceed to the
next counter. (0.1 - 5 seconds）
If you set it to "00", then Auto memory/Reset function
will be ineffective.
Use ▲▼ key to select the timing (second) and press
MEM key to save and proceed to the next.
(Press MD key to proceed without saving. Press C key
to return to RUN measuring mode.)
Select the torque unit
（N
･
m ／ kgf
･
cm ／ kgf
･
m ／ lbf
･
in ／ lbf
･
ft）
Unit conversion table
Conversion factores
N
・
m
→
kgf
･
cm 10.1972
N
・
m
→
kgf
･
m 0.101972
N
・
m
→
lbf
･
in 8.8508
N
・
m
→
lbf
･
ft 0.73756
Rounding of the converted gures
100.0[N
･
m] × 0.73756 ＝ 73.756 ≒ 73.8[lbf
･
ft]
73.8[lbf
･
ft] ÷ 0.73756 ＝ 100.05 ≒ 100.1[N
･
m]
※ Converted gures are rounded as above.
Accordingly, the resulted gures may have a margin of errors.
※ Unit conversion is made based on N.m values with the above conversion factors.
※ All the memory and torque setting values are converted when making a unit change.
