Standards Relay contact output : contact specification 1c contact capacity
250V AC3A(resistance load).
SSR drive voltage output: OFF time; 0V DC ON time; 12V DC Loaded
resistance over 600Ω
. (It may vary according to a
calculation with SSR inner resistance.)
1～5V DC output : Output voltage 1～5V DC Loaded resistance over 1KΩ.
Possible output range 0.6 ～5.4V DC.
0～10V DC output: Output voltage 0～10V DC Loaded resistance over 1KΩ.
Possible output range 0 ～11V DC.
4～20mA DC output: Output current 4～
20mA DC Loaded resistance below
600Ω.
Number of
patterns/steps
Number of pattern x No. of steps : Max.64 can be set.
Step time
0 ～99 hrs. 59 min.
Time accuracy
Set value ±(0.5% + 0.5 sec.)
Run times
0 ～99 times (0 for continuation)
Program area
Wait action
Wait zone: 0 ～100℃(
) Wait time: 0～1 hr.59 min.
Event output Contact specification 1a contact point Contact capacity
250V AC 0.5A(resistance load) or 125V AC 1A (resistance load)
RUN signal
input
OFF time voltage: 32V DC ON time current: 6mA DC
Allowable resistance between terminals : ON time: max.333KΩ
OFF time: min. 500KΩ
Minimum input time: 500mSEC and over
Additional
Function
Communication
Communication standard: in accordance with RS-485
Network : Multi-drop method (Max. 31 stations for each)
Communication distance: Max. 500m
Communication address : 1 ～99 stations
10.MAINTENANCE AND INSPECTIONS
Troubles Check points
Display does not come out. Is instrument correctly inserted in the case?
Are power terminals correctly connected?
Is power sufficiently supplied?
display
Memory error. If this still appears after putting power again , repair the unit.
display
A/D conversion error. If this still appears after putting power again, repair the unit.
display
Auto-tuning error. The display can be released by entering any key operation.
Be sure to check the following points, then try auto-tuning again.
Is a sensor correctly connected? Does process value indicate normal?
Is control output normal? Does temperature correctly rise(or fall)?
display
display
Unstable process value
Is the sensor normal? (Does another unit make the same error?)
Is the sensor correctly connected?
Is the type of sensor correctly setup?
Is correct value installed for the sensor correction value?
No noise mixing?
Unable to start Is the process value appropriate for any of the run steps after selecting PV Start?
Insufficient control Value setting of PID constant, control sensitivity and fuzzy strength all proper?
Temperature does
not increase(or decrease)
Is output terminal correctly connected?
Is control type correctly set up?
If any of the troubles still exists after following the above instruction, or for any other cases, contact our Sales
Department.
Head office : 10213-23,Tana,Sagamihara Kanagawa 229-11 Japan
Phone: 81-427-77-3311 FAX:81-427-77-3751
TOHO ELECTRONICS INC.
All rights reserved. 42-0167-C
