Tojock DVP506 - Additional Features Explained; Technical Specifications; Trouble Shooting

6
1.TITLE: Play the first title in addition to DVD disc
2.Menu: Display the DVD menu
5.Additional Features Explained
1.Use USB Memory Sticks / Thumb Drives
1)Turn off the player.
2)Insert the USB Memory Stick (with AVI, MPG4, or JPEG files) to the USB Port on the
front of the player.
2.Turn on the player. Press and hold the CD/USB button on the remote control.
1)The Folder/Files list will appear on the screen.
2)Use the directional buttons to select and highlight the desired folder or file.
3)Press the ENTER button to con- firm and begin playback.
6.Technical Specifications
Power source: AC 110-240V ~ 50-60Hz Power Consumption: 11W
Remote Control: DC3V, 2xAAAbatteries (not included) Video Signal System:
AUTO/NTSC/PAL
Frequency Response: ±1dB(20Hz~20KHz) Signal Noise Ration: ≥90dB
Audio Distortion: ≤1%
Channel Separation: ≥80dB(1KHz) Dynamic Range: ≥80dB(1KHz) Audio Out (Output
Level): 2 ± 0.1V; Analog Audio: Load Impedance 10KΩ
Video Out (Audio Out): Output Level: 0.5Vp-p; Digital Signal: Load impedance: 75Ω
Video Out Output Level: 1Vp-p
Load Impedance: 75Ω ,imbalance,negative polarity Laser Bandwidth: wave length 645 -
660 nm
Laser Power: Class 1
Supported Discs: VCD/CD/MP3/PhotoCD/SVCD/JPEG/MPEG-4 Supported Video Files:
AVI/DIVX/MPG/MPEG4/VOB/FLV (720*480/576)
7.Trouble Shooting
Problem
What to Check
The power light does
not come on
Plug the power cord into a wall outlet
Try a different outlet
No Picture
Select the appropriate video input format on your TV in order to
receive the player's output signals.
Fully insert the plugs on the video cable into the
corresponding jacks.
No Sound
Fully insert the plugs on the audio cable into the
