Document Ref 947571-001 Rev 2 Page 2-3
Quantium 110 & 210 Installation Manual Site Preparation
Q110 DISPENSER
Zone 2
Zone 1
Non-hazardous zone
Note:- On this drawing all zone 2 areas are external of the dispenser.
Zone 1 is internal in the dispenser.
Island Level
Zone 1
Zone
2
Zone 1
Hydraulic
housing
Calc Head
509427
Zone
2
Zone
2
Zone
2
1471
350
200 200
50
1080
62
328.5
200 200
