Tokheim Quantium 110 User Manual

Document Ref 947571-001 Rev 2 Page 2-11
Quantium 110 & 210 Installation Manual Site Preparation
2.3.3 SUBMERGED CONNECTIONS
Standard Submerged Connection
Riser shear valve height
133
Dimensions shown from the bottom of the base
117
(40/49)
Ø1.5"
End threaded
Riser nut coupling height
Submerged Connection with Nefit Adaptor & Tokheim Shear Valve
Adapter NEFIT
Pipe 903583
201
70
Island Level
117
Driptray
height
Filter Level
NEW DRAWINGS REQUIRED
