SURFACE CHARGE NOTICE:
The battery will hold a surface charge if the engine has been running or after the battery has been charged. The tes-
ter may prompt you to remove the surface charge.
A. Follow the instructions indicating when to turn the headlights on and off or apply a load into the battery.
IN VEHICLE:
SURFACE CHARGE
IN VEHICLE? YES
TURN HEADLIGHTS
ON FOR 15 SECS
OUT OF VEHICLE:
SURFACE CHARGE IN
VEHICLE? NO
TESTING
B. The tester will resume testing after it detects that the surface charge is
removed.
TESTING
10. Test the battery for few seconds.
11. Press the keytoselectbatteryfullychargedornotiftesterasks.
Press«ENTER»toconrmchoice.
IS BATTERY
CHARGED? YES/NO
12. When the test is completed, the display shows the actual volts and the actual CCA and internal resis-
tance. {Press the keytoread:SOH(STATEOFHEALTH)andSOC(STATEOFCHARGE)}.
13. One of the six test results will be displayed:
GOOD & PASS
*The battery is good and capable of holding a charge.
GOOD & PASS
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xxmΩ
GOOD & RECHARGE
*The battery is good but needs to be recharged.
GOOD & RECHARGE
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xxmΩ
CAUTION
*The battery may be serviced but decrease the capability of starting the
engine gradually. The battery may fail under extreme climate conditions.
There may be a poor connection between the vehicle and the battery affect
the charging function. Please pay attention to the battery for replacement
considerationandchargingsystemchecking.
CAUTION
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xxmΩ
