5
1. Straightedge.
2. Large slot and large Phillips screwdrivers.
3. Socket Wrench (recommended) and
Adjustable wrench.
MODEL 10LP-A
Speed 4000R.P.M
Diameter of arbor 5/8”(16mm)
Diameter of cut 10”(254mm)
MAX. depth of cut 3-1/8”(79mm)
MAX. depth of cut at 45. 2-1/8”(54mm)
Distance in front of blade 10.23”(260mm)
Table (LXM) 686X512mm
Extension wing(LXW) 686X305mm
Motor 1.5HP/240V
Net Weight 116.4kg
Gross Weight 136kg
All specification, dimensions and design characteristics shown in this catalogue are
subject to change without notice.
SPECIFICATIONS
