2. Grounded, cord-connected tools intended
for use on a supply circuit having a nominal
rating less than 150V:
This tool is intended for use on a circuit that
has an outlet that looks like the one illustrated
in Sketch A in Figure1.2. The tool has a
grounding plug that looks like the plug
illustrated in Sketch A in Figure 1.2. A
temporary adapter, which looks like the adapter
illustrated in Sketches B and C, may be used to
connect this plug to a 2-pole receptacle as
shown in sketch B if a properly grounded outlet
is not available. The temporary adapter should
be used only until a properly grounded outlet
can be installed by a qualified electrician. The
green-colored rigid ear, lug, and the like,
extending from the adapter must be connected
to a permanent ground such as a properly
grounded outlet box.
※ Note: In Canada, the use of a temporary
adaptor is not permitted by the
Canadian Electrical Code.
3. Grounded, cord-connected tools intended
for use on a supply circuit having a nominal
rating between 150-250V, inclusive:
This tool is intended for use on a circuit that
has an outlet that looks like the one illustrated
in Sketch D in Figure 1.2. The tool has a
grounded plug that looks like the plug
illustrated in Sketch D in Figure 1.2. Make
sure the tool is connected to an outlet having
the same configuration as the plug. No adapter
is available or should be used with this tool. If
the tool must be reconnected for used on a
different type of electric circuit, the
reconnection should be made by qualified
service personnel; and after reconnection, the
tool should comply with all local codes and
ordinances.
Fig.1.2
GROUNDING
PIN
COVER OF GROUNDED
OUTLET BOX
Fig.1.1
GROUNDING PIN
COVER OF GROUNDED
