ASSEMBLY INSTRUCTIONS
Step 6
Insert the seat post (D) into the main frame
through the plastic sleeve. Select the ideal
hole position on the seat post. Insert the knob
(E-6) into the hole. Tighten fully the knob.
Step 7
Connect the saddle (D-6) and the slider (D-
5) s.
Attach the slider onto the top of the seat
post and the secure using the horizontal
adjusting knob (D-1) and one flat washer (D-
2).
6
