TOORX MSX 60 - Page 9

Attach the front vertical frame (3) onto the main base frame(8) , carefully align the holes and secure them
with 2 pcs M10×70 carriage bolts(64), one pc bracket (25),2pcs 2pcs Ø10 washers (67) and 2 pcs M10
Aircraft nuts (69).
Assembly instructions
9
Step 2
