KIT INSPECTION
Before starting to build, inspect the parts to make
sure they are of acceptable quality. If any parts are
missing or are not of acceptable quality, or if you
need assistance with assembly, contact Product
Support. When reporting defective or missing parts,
use the part names exactly as they are written in the
Kit Contents list on this page.
Top Flite Product Support:
3002 N Apollo Drive Suite 1
Champaign, IL 61822
Telephone: (217) 398-8970
Fax: (217) 398-7721
E-mail: airsupport@top-fl ite.com
KIT CONTENTS
1. Fuselage
2. R&L inboard wing panels, inboard fl aps, fl ap
servo hatches
3. R&L outboard wing panels, outboard fl aps, ailerons,
fl ap and aileron servo hatches
4. Horizontal stabilizer, elevators, rudder servo hatches
5. R&L vertical stabilizer, rudders
6. R&L fi berglass nacelle covers
7. Fiberglass engine cowls
8. R&L ply/balsa/hardwood nacelle assembly
9. R&L carburetor intakes
10. Replica engines
11. Main landing gear doors
12. Fiberglass tail-gunner cabin
13. Tail-gunner canopy
14. Nose-gunner canopy bottom
15. Nose-gunner window
16. Cockpit canopy
17. Nose-gunner cabin fl oor, ammo tray, kneeling
pad, ammo boxes and tops (4)
18. Nose-gunner cabin back
19. Tail-gunner cabin bulkhead, armor plate,
mounting bracket
20. Pilot/co-pilot seat backs
21. Fiberglass ADF “football” antenna w/magnets
22. Top turret tandem machine guns
23. Nose-gunner machine gun
24. Top machine gun turret canopy
25. R&L side gun packs
26. Nose gear door
27. Nose gear wire
28. 2-5/8" [68mm] nose wheel
29. (7) 6-1/8" [155mm] machine gun barrels (1-nose
gun, 2-top turret, 4-external gun packs, (2) 4-7/8"
[125mm] waist machine gun barrels, (2) 4-7/8"
[125mm] tail-gunner machine gun barrels w/4-40
threaded inserts
30. Cockpit fl oor (painted fl at black)
31. R&L oil cooler air scoops
32. R&L waist gun windows
33. Molded plastic fi xed main landing gear blocks
34. R & L main landing gear wires
35. (2) 3-7/8" [98mm] main wheels
36. (2) 420cc Fuel tanks w/hardware
37. 30 x 440mm center main wing tube (1), 10 x
305mm forward and aft main wing tubes (2, one
end threaded w/nylon inserts), 22 x 295mm outer
panel wing tubes (2), 10 x 150mm outer panel
wing tubes (2, one end threaded w/nylon inserts)
38. Elevator joiner wire
ORDERING REPLACEMENT PARTS
To order replacement parts for the Top Flite
B-25J Mitchell ARF, use the order numbers in the
Replacement Parts List that follows. Replacement
parts are available only as listed. Not all parts are
available separately (an aileron cannot be purchased
separately, but is only available with the wing kit).
Replacement parts are not available from Product
Support, but can be purchased from hobby shops
or mail order/Internet order fi rms. Hardware items
(screws, nuts, bolts) are also available from these
outlets. If you need assistance locating a dealer to
purchase parts, visit www.top-fl ite.com and click
on “Where to Buy.” If this kit is missing parts, contact
Product Support.
REPLACEMENT PARTS LIST
Order Number Description How to purchase
Missing Pieces .................. Contact Product Support
Instruction Manual ............ Contact Product Support
Full-Size Plans ..................................... Not Available
Contact your hobby supplier to purchase these items:
TOPA1700 Wing Set
TOPA1701 Fuselage Set
TOPA1702 Tail Set (Fins and Stabilizers)
TOPA1703 Left Engine Nacelle Assembly
TOPA1704 Right Engine Nacelle Assembly
TOPA1706 Cowl
TOPA1707 Dummy Engine
TOPA1708 Tail-gunner Cabin
TOPA1709 Gunner Windows
TOPA1710 Wing Tubes
TOPA1711 Landing Gear Set
TOPA1712 Landing Gear Doors (All)
TOPA1713 Cockpit Windscreen
TOPA1714 Cockpit Interior
TOPA1715 Nose-Gunner Window Assembly
TOPA1716 Nose-Gunner Cabin
TOPA1717 Machine Gun Set (All)
TOPA1718 Fuel Tank
TOPA1719 Propeller Hub
TOPA1720 Decal Set
TOPA1721 Building Stand
