8-9. Upgrade Verify
VMC to UCA2
90h 05h 137 03h 21h
UCA2 to VMC
90h 07h 137 CRC16 H CRC16 L 03h E8h
8-10. Read Start
PC to UCA2
90h 05h 39 03h CS
UCA2 to PC
90h 05h 50h 03h E8h ACK
90h 05h 4Bh 03h E3h NAK
8-11. Read Finish
PC to UCA2
90h 05h 38 03h CS
UCA2 to PC
90h 05h 50h 03h E8h ACK
90h 05h 4Bh 03h E3h NAK
8-12. Reading
PC to UCA2
90h LEN 40 BLOCK LINE SIZE 03h CS
BLOCK : 0 LINE : 0~3 SIZE : 64
UCA2 to PC
90h LEN 40 block line data0
data1 .. Data63 03h CS
