UCA2
2
2.Specification
2-1. General
Acceptance Rate 96 % or greater
Accepting Speed Approx. 3 coin/sec
Interface PULSE / RS232 (TTL level)
Installation Indoor
Coin Parameters (D) : 20mm-32mm( T ) : 1.2mm- 3.2mm
2-2. Electronic
Power Source 12V DC ± 10%
Power
Consumption
Standby : 0.05A / 0.6W
Operration Current : 0.20A / 2.4W
Maximum : 0.50A / 6W
Temperature
Range
Operating Temperature : 0° C~60° C
Storage Temperature : -10° C~80° C
Humidity : 20%~70%RH
(no condensation)
2-3. Machine
Weight 350 ±10 g
Outline
Dimension
124 x 72.4 x 147.5 mm
3.Packing List
Main UCA2 Coin Acceptor
Accessories
User Guide
Harness
Screw set
