Topcom ultra range series - Commissioning the Charging SR1200 c and R112 Repeater Station

9
8OWUD5DQJH
(1*/,6+
 &RPPLVVLRQLQJWKHFKDUJLQJ65FDQG5
5HSHDWHUVWDWLRQ
1. Bottom of the charging/Repeater station
2. Mains adapter
• Put the cradle feet as shown below on the charger bottom:
- For wall mounting you have to use ‘:$//’
- For desktop charging you have to use ‘'(6.’
2.2.1
Wall mounting
The charging/Repeater station can be wall mounted as shown on
the picture below.
The drilling holes need to be drilled horizontally 3 cm from each
other:
2
1
DESK
WALL
