Battery Compartment and Card Slots
Connector Ports
1 Battery Pack, Removable
2 Battery Door
3 Micro SIM Card Slot and
Micro SD/SDHC Card
Slot (underneath card
retainer)
4 Flexible Card Retainer
5 Battery Compartment
6 Docking Connection
7 Hand Strap Attachment
Point (2 on each side)
2
1
5
4
3
6
7
8 Connector Port Protector
9 12 VDC Power Input Jack
10 USB 3.0 Host, Full Size
11 Audio Jack
12 Storage Slot for Fine Tip
Stylus
9
10
11
8
12
