6. Connect Section Loom (LL07013 or LL07023) to individual connectors on the Liquid
Systems (SA) section module. Ensure section valve number matches connector number.
e.g., valve No. 1 plugs in to connector No.1. Insert dust plugs into un-used connectors on
the Section Loom.
Insert dust plugs in
to
un-used connectors
