Topdon BT50 - 2. Cranking Test: Preparation and Steps; 2.1 Before Conducting Test; 2.2 Performing the Test; 2.3 Interpreting Cranking Results

EN | 13
2.2 STEPS
1) Press the "OK" button to display the main menu. Then
select "2. Cranking Test" and press the "OK" button to
conrm.
2) Start the engine within 30 seconds.
3) The result will show as below:
Please refer to the table below to conrm the test result for
12V batteries.
GOOD≥10.7V
9.6~10.7V
<9.6V
NORMAL
CRANKING LOW
Cranking Voltage Conclusion
29
6. About
Crankingt Test
TIME 1003ms
VOLTAGE 11.59V
