TOUCHING.
• ALWAYS DISCONNECT THE NEGATIVE CABLE FROM THE
BATTERY FIRST AND RECONNECT IT LAST.
3) Once the clamps are properly connected, the battery tester
will power on automatically and be ready to conduct tests.
1) Select BATTERY TEST and press [ENTER / PRINT].
SECTION 4
HOW TO USE
Battery Test
WARNING:
Before the test, the engine and all other accessory loads
must be off to ensure accurate results. The battery testing
function only applies to 12V lead-acid batteries (24V
batteries are not supported).
(Red) (Black)
EXIT
MAIN MENU
BATTERY TEST
CRANKING TEST
CHARGING TEST
REVIEW DATA
LANGUAGE
ABOUT
ENTER
Figure 3.3.1
Figure 4.1.1
EN I 13
