SETTING RATE
600CCA
CCA
ENTER
Figure 4.1.5
5) The test result will appear soon on the tool's display.
Battery Test Terminology:
100% 638CCA
100% 12.67V
3.57mΩ
600CCA
EXIT
BATTERY TEST
GOOD BATTERY
HEALTH
CHARGE
INTERNAL R
RATED
ENTER
Figure 4.1.6
HEALTH (SOH)
CHARGE (SOC)
INTERNAL R (Internal
Resistance)
The state of health shows the difference between the
battery being tested and a new battery, considering
cell aging. The SOH is dened according to the
maximum battery charge ratio and its capacity.
The state of charge describes the difference between
a fully charged battery and the same battery in
use. It analyses the remaining quantity of electricity
available in the cell. The SOC is established according
to the battery's remaining charge ratio, divided by the
maximum charge that the battery can deliver.
The internal resistance is the opposition to the current
ow presented by the cells and the battery itself,
generating heat. Its electronic resistance and ionic
resistance directly impact this indicator.
EN I 16
