1) Select CRANKING TEST and press [ENTER / PRINT].
2) The test will start by prompting you to crank the engine.
Follow the instructions and start the engine.
EXIT
EXIT
MAIN MENU
CRANKING TEST
BATTERY TEST
CRANKING TEST
CHARGING TEST
REVIEW DATA
LANGUAGE
ABOUT
PLEASE START ENGINE
30
ENTER
ENTER
Figure 4.2.1
Figure 4.2.2
RATED
The CCA value you entered in the previous step,
that is, the CCA value listed on the battery label. The
difference of the rated CCA between the actual CCA
determines the test result to a certain extent.
Cranking Test
WARNING:
Before the cranking test, the engine and all other accessory
loads must be off in order to ensure accurate results. This
test applies to both 12V & 24V lead-acid batteries.
EN I 17
