Topdon BT600 - Performing a Charging Test

3) The test results will appear on the display.
Cranking Time and Cranking Voltage:
• The Cranking Time refers to the time it takes for a vehicle to
start the engine.
• The Cranking Voltage refers to the battery voltage while the
engine is starting. Cranking Voltage should always be higher
than 9.6V for passenger vehicles and 19.2V for commercial
vehicles.
1) Select CHARGING TEST and press [ENTER / PRINT].
EXIT
CRANKING TEST
NORMAL
CRANKING TIME
1599ms
10.33 V
ENTER
Figure 4.2.3
Charging Test
WARNING:
Always start the engine before performing the charging
test. This test applies to both 12V & 24V lead-acid batteries.
EXIT
MAIN MENU
BATTERY TEST
CRANKING TEST
CHARGING TEST
REVIEW DATA
LANGUAGE
ABOUT
ENTER
Figure 4.3.1
EN I 18
