4) Installation and use instructions ( );Ref.F
3.7- PACKAGE
2);) Window mounting brackets and screws for aluminum (S2 DRef.
1)Actuator ( );Ref.A
or
3)Actuator bracket and screws for aluminum ( );SA Ref. C
SHOULD ANY ANOMALY BE DETECTED, IT IS FORBIDDEN TO INSTALL THE ACTUATOR, AND IT IS
COMPULSORY TO REQUIRE TECHNICAL ASSISTANCE FROM YOUR DEALER OR THE
MANUFACTURER.
5) Safety plate ( ).Ref. G
Each package of the product contains:(Fig. )4
W:indow opening application
2) Window mounting brackets and screws for aluminum (S1 BRef. );
Sun blades or window louvers :application
1) Actuator ( );Ref. A
3) and screws ( );T2 ERef.
5) Safety plate ( ).Ref. G
4) Installation and use instructions ( );Ref.F
MAKE SURE THAT THE ABOVE DESCRIBED COMPONENTS ARE CONTAINED IN THE PACKAGE, AS
WELLAS THAT THE ACTUATOR HAS NOT BEEN DAMAGED DURING TRANSPORT.
3.6- RATING PLATEAND “CE” MARKING
• type and model
• protection degree (IP)
• symbol of double insulation (only for mod. S80/230V)
The rating plate is an adhesive plate in polyester, silk-screen printed in black, having the following size: L=24
mm - H=60 mm
The “CE” marking certifies the compliance of the machine with the essential safety and health requirements
foreseen by the product European Directives.
It is applied externally on the actuator. The plate bears in readable and indelible way the following data:
• absorbed electric power P (W)
• thrust and tractive force F (N)
• idle translation speed (mm/s)
• “CE” marking
•type of service S2 (min)
• voltage and intensity of power supply (V -A)
• symbol of WEEE Directive 2002/96/CE
• logo and address of the manufacturer
• serial number
10
3- TECHNICAL DESCRIPTION
INSTALLATION AND USE INSTRUCTIONS
S80
