【Code meaning】
Information Operating
Manual resetting
Refer to the progress of manual reset
Overloading
Remove the load on desktop till it less than 800N (175 LBS)
for further operation
Anti-Collision function
It can be used normally after removing the obstacle
Operated continuously
without suitable rest
Make the desk rest around 15minutes for further operation
Code
rES
ovr
E-2
dut
【Trouble shooting】
Operating
Stop the operation and reset, refer to Manual reset
Check the cables and ensure they are well connected, and the
height-adjustable desk can be used normally after manual reset
Code
E-4 / The height between two legs exceed 1 inch
E-3
8
Code meaning and Trouble shooting
【Technical Data】
Item Data
Input voltage
220~240VAC / 100~130VAC
output voltage
24VDC
Max loading
1000N
Height range
(without desktop)
70～120（
27.6"～47.3"）
Duty cycle
2 min on/ 18 min off
Technical Data
