TECHNICAL DOCUMENT
PURPOSE
This document gives instructions on installing a 1100M Power Drawbar.
LOOKING FOR A VIDEO?
Before you begin, select the image below to watch a walk-through video of this entire installation
procedure.
PRODUCT INFORMATION
Product: 1100M/770M Power Drawbar Kit (PN38436)
Quantity Description
1 1/4 in. Plastic Tube
1 1/4 in. Push-to-Connect Air Fitting Adapter
4 4 in. Nylon Cable Tie (PN31719)
1 Anti-Seize (PN 31273)
1 Extend (Red) Air Line
1 FRLFilter-Regulator-Lubricator (PN 32457)
1 M10 × 16 mm Shoulder Screw (PN 35926)
1 Power Drawbar Button Assembly (PN 38216)
1 Power Drawbar Cylinder Assembly (PN37750)
1 Quick-Release Pin (PN 37284)
1 Retract (White)Air Line
8 Power Drawbar Spring Washer (PN 31319)
Note: If any items are missing, we can help. Email support@tormach.com to contact Tormach Technical
Support for guidance on how to proceed.
