Initial Conguration
1. Power on the controller according to Power O/On Procedure detailed earlier in this document.
2. When the end-user license agreement appears, review and click Agree to connue (see Figure 1).
3. Select the machine-specic controller conguraon opon from the menu choices (see Figure 2).
NOTE: Step 4 and Step 5 may not appear on screen depending on machine-specic conguraon selected.
4. An informaonal window appears requiring Mesa card interface reprogramming; click OK to connue.
Aer reprogramming is complete, click any key on the keyboard to close.
5. The soware prompts for restart, click OK. This allows the controller to safely power o.
6. Power on the controller again; PathPilot interface launches.
Software Update
Before using PathPilot, ensure controller’s soware is up-to-date with the latest release.
NOTE: Updates do not need to be applied sequenally. Simply download the latest update as follows.
1. Download the most recent PathPilot update le (vX.X) from www.tormach.com/updates.
2. Transfer the le to a USB drive and plug the USB drive into the PathPilot controller.
Figure 1
Figure 2
Congure for new PCNC1100 - Series 3
Congure for new PCNC770 - Series 3
Congure for new PCNC440
Congure for new 15L Slant-PRO
