Product description
Product description
General product overview
10
9
12
20
3
7
16
1
16
8
13
11
17
4
*
* Example garage door illustration
1. Drive head including LED module 11. Door connector attachment
3. Rail (model example) drive side 12. Linking bar
4. Carriage 13. Central support
7. Rail connector (model example) 16. Support straps drive head
8. Rail (model example) door side 16. Support straps track
9. Tensioner 17. Mains cable, 1.2 m
10. Wall bracket 20. Telescopic tting for sectional doors (accessory)
Control elements
A
C
B
A1
D
15
1
A. Numerical display (A1 digital point)
C. OPEN / Start button
B. CLOSE button
D. Program button (PROG button)
1. Drive head
15. Hand transmitter
