106
Parting and Beading Tools
Lock the seat with the bottom
screw (6) in the straight position
(0°). The seat should touch the
stop (7).
Mount the tool protruding (P)
75–100 mm (3–4") and lock it
with the top screw (5).
Set the edge angle by adjusting
the Universal Support. When
replicating an existing angle,
use the Marker Method, (p 41).
Press with your fingers close to
the edge for best control while
your other hand ensures that
the tool is vertical.
Ensure that the entire flange
of the jig is in contact with the
Universal Support.
When the first side is ground
then turn the tool around and
grind the other side.
Grind until the bevels are sym-
metrical. If necessary grind the
first side again.
Honing. Move the Universal Support to the honing wheel side
and hone the bevels with the tool still mounted in the jig. Set the
Universal Support so that you get the same honing angle as the
grinding angle. Use the Marker Method.
The Open Seat is Used
