Tornado 99130 Owner's Operation And Maintenance Manual

23
BRUSH LIFT ASSEMBLY
1 4 02663 Retaining Ring
2 2 18122 Pin
3 4 16581 Washer-Plain ½” ID (ZP)
4 1 18196 Weldment, Brush Lift Pedal
5 1 18203 Pedal Mat
6 1 18083 Clevis Pin
7 2 18081 Clevis
8 2 18093 Nut
9 1 18191 Oft Rod
10 1 18399 Screw – (20” Models 99125 & 99126 Only)
11 1 02568 Washer – (20" Models 99125 & 99126 Only)
12 1 18758 Weldment Brush Release Latch
13 1 18126 Spring
14 2 18179 Bearing
15 2 03955 Bushing
16 2 03321 Washer
17 2 16671 Screw
18 2 12554 Washer, Nylon
19 1 18185 Arm, Left Hand – (20" Models 99125 & 99126 Only)
*19 1 18186 Arm, Left Hand – (24" Model 99130 Only)
20 1 18107 Spacer
21 13 03736 Washer – (20" Models 99125 & 99126 Only)
*21 10 03736 Washer – (24" Model 99130 Only)
22 1 18165 Pin
23 8 03947 Retaining Ring – (20" Models 99125 & 99126 Only)
*23 6 03947 Retaining Ring – (24" Model 99130 Only)
24 3 15677 Screw, Shoulder
25 4 18872 Screw
27 2 07132 Washer, Wave
28 3 01589 Nut
29 2 18164 Plate, Adjustment
30 2 18163 Pin
31 4 16347 Bearing, Flange
32 2 18195 Bearing, Sleeve
33 1 18166 Arm, Right Hand – (20" Models 99125 & 99126 Only)
*33 1 18167 Arm, Right Hand – (24" Model 99130 Only)
34 1 18184 Weldment, Brush Eddied – (20" Models 99125 & 99126 Only)
*34 1 18193 Weldment, Brush Lift – (24" Model 99130 Only)
35 1 18403 Link - (20" Models 99125 & 99126 Only)
36 1 18405 Pin - (20" Models 99125 & 99126 Only)
*36 1 18083 & 03395 Pin – (24" Model 99130 Only)
37 1 18398 Spring - (20" Models 99125 & 99126 Only)
38 1 18397 Weldment, Adjustment - (20" Models 99125 & 99126 Only)
39 1 03395 Cotter Pin
40 1 19078 Pin-Spring
*Not Shown
Item No. Qty. Part No. Description

Tornado 99130 Specifications

General

Brand	Tornado
Model	99130
Category	Floor Machine
Language	English
