Tornado CK 14/1 PRO User Manual

15
How to Clean the Brush Head Hose
CAUTION: Unplug the vacuum cleaner before performing any of these steps.
1. Remove the wand from the wand / hose holder as shown on
page
2. Squeeze the tabs on both sides of the quick clean-out port
and pull away from the vacuum (Fig. 23).
3. Check above and below the port opening for obstructions.
4. Remove any obstructions.
5. Replace the quick clean-out port by squeezing both tabs and
pushing it back into the wand / hose holder.
Fig. 23
Circuit Breaker Protection
CAUTION: Turn off and unplug the vacuum cleaner before performing any of these steps.
Your new vacuum cleaner is circuit breaker protected to prevent motor damage due to airow or brush obstruction. Should
your vacuum cleaner experience an obstruction, the circuit breaker will trip and safely turn off the motor.
To reset circuit breaker:
1. Press the on/off switch to the off position “O” and unplug the vacuum cleaner cord.
2. Check brush and remove any entangled objects. Remove bottom plate to access obstruction if necessary (see
page 9)
3. Check for airow obstruction and remove obstruction (full bag, clog in brush head hose, clog in wand/hose,
clogged lters, etc.)
4.After removing obstruction reset the circuit breaker by pushing the reset button with a pointed object and resume
operation (Fig. 24).
NOTICE: Do not repeatedly reset circuit breaker button without removing obstruction, motor failure may result and void
warranty. If vacuum cleaner fails to turn on, contact a Tornado Authorized Service Center or Distributor.
CK 14/2CK 14/2
CK 14/1
Fig. 24
