Tornado EZ User Manual

27
RECOVERY TANK w/VAC MOTOR ASSEMBLY
1 1 18741 Access Cover, Recovery Tank
2 1 18799 Deflector, Intake
3 1 15088 Adaptor Fitting
4 1 18789 Cover Retaining Cable
6 1 18887 Float Assembly
7 1 18742 Gasket
8 1 18790 Cable Clasp
9 1 31235 Assembly-Vac. Motor
10 2 05781 Gasket
11 1 15096 Fitting, Female Adapter
12 1 18259 Sleeve, Hose
13 1 18477 Grommet-Rear Panel
14 1 18241 Bracket Hose Support
15 1 18747 Hose, 1 1/2"
16 2 18253 Screw-T.F.PLT60, Pan Head #8-16 X ¾”
17 1 18226 Plug
18 1 18358 Strap, Hose Plug Retainer
19 1 18357 Sleeve, Recovery Drain
20 6 01734 Screw
21 6 01246 Lockwasher
22 3 18671 Clip, Drain Hose
23 6 01905 Lockwasher
24 6 01993 Screw
25 3 18439 Plate
26 1 19286 Hose, 1 1/2"
27 1 16091 Clamp, Hose
28 1 18401 Sleeve
29 1 18052 Fitting, Male Adapter
30 1 18740 Tank, Recovery
31 1 19398 Vac Motor Intake Screen
32 1 18846 Housing, Vac Filter Spacer
33 1 17392 Filter Cover Assembly Cable Clamp
34 2 18342 Screw
35 3 14142 Washer
36 1 15183 Screw-Hex.Head Cap ¼”-20 x 1-1/4”(SS)
37 3 18333 Screw-Phil.Pan ¼-20 x 1.00 (ZP)
38 2 18349 Spacer
40 1 18847 Gasket
41 1 17508 Nut
42 1 18885 Washer
43 2 18886 Washer
44 1 18688 Battery Tray
45 1 18687 Vac. Motor Exhaust Hose
46 1 18686 Muffler
47 1 18692 Battery Spacing Bracket (12V Only)
48 2 18706 Tie Wrap
49 1 14858 Hose Clamp
50 1 04651 Screw-TCT(F) Pan Hd. #10-24 x ½”
51 3 00851 Washer-Plain ¼”
*52 2 98799 Battery (99105A & 99125A)
*53 4 99506 Battery (99105B, 99125B & 99130)
*54 1 99510 Battery Charger (99105A & B, 99125A & B, 99130)
*55 1 18692 Bracket – Tray (99105A & 99125A)
*56 2 30725 Cable (99105B, 99125B & 99130)
*Not Shown Unless indicated otherwise, Part Number applies to all models.
Item No. Qty. Part No. Description
