Tornado EZ User Manual

29
SQUEEGEE ASSEMBLY
1 1 03868 Nut
2 2 16581 Washer
3 1 18314 Handle, Squeegee Control
4 2 16347 Bearing, Flanged
5 1 18655 Push Nut
6 5 16136 Screw
7 1 18817 Bracket, Handle Pivot
8 1 03320 Screw
9 1 19910 Cable Assy-Squeegee
10 2 03660 Screw
11 1 18651 Plate, Control Cable Clasp
12 2 10894 Nut
13 2 30227 Pin - Cotter (Ext. Prong)
14 2 18400 Wheel
15 2 30226 Pin-Clevis .320 DIA / 1-1/4"LG
16 4 00696 Washer-Plain #10 ID (ZP)
17 2 17130 Nut Acorn
18 2 17400 Spacer
19 2 11053 Rub Wheel
20 2 07132 Washer, Wave
21 1 18136 Channel, Outer - 20" (Model 99125 Only)
*21 1 18137 Channel, Outer - 24" (Models 99126 & 99130 Only)
22 1 18709 Squeegee Blade Set - 20" (Model 99125 Only)
*22 1 18710 Squeegee Blade Set - 24" (Models 99126 & 99130 Only)
23 1 18663 Squeegee Blade Retainer - 20" (Model 99125 Only)
*23 1 18664 Squeegee Blade Retainer - 24" (Models 99126 & 99130 Only)
24 2 18680 Screw-Flat Hd. Cap
26 2 18681 Screw
27 1 03320 Screw
28 1 16586 Lockwasher
29 1 03914 Washer
30 1 18145 Bearing
31 1 18146 Pivot
32 1 18141 Weldment, Towing Arm
33 3 18119 Knob
35 4 01577 Lockwasher
36 4 18111 Screw
37 1 18142 Shaft, Pivot
38 1 16254 Cotter Pin
39 2 16347 Bearing
40 1 18114 Weldment, Pivot Frame
41 1 18144 Weldment, Pivot Frame
42 1 18568 Spring
43 1 18138 Spring Adjuster
44 1 18176 Pin
45 1 18206 Weldment, Wheel Support
46 1 18650 Bracket, Control Cable
47 1 18251 Grip
48 3 18253 Screw
49 1 18548 Lever Stop Bracket
50 4 14142 1/4" Flat Washer
51 1 01574 1/4" Lock Washer
52 1 01497 1/4" - 20 Nut
53 1 18695 Eye Bolt
54 2 15560 #4 - 40 Keps Nut
55 2 18323 #4 - 40 x 5/8 Pan Head Screw
56 1 18818 Switch
57 4 03301 Washer-Plain 5/16” ID (ZP)
58 1 19796 Plate-Control Cable Clasp
59 2 00851 Washer-Plain ¼”
*Not Shown Unless indicated otherwise, Part Number applies to all models.
Item No. Qty. Part No. Description
