31
CONTROL/INSTRUMENT SYSTEM
1 1 18221 Gauge, Battery Condition
2 10 18253 Screw
3 1 18218 Indicator Light, Red
4 1 18217 Switch
5 2 18216 Switch
6 1 18212 Panel, Instrument
7 2 15560 Nut-Hex.Lock(Keps) # 4-40
8 1 15542 Switch, Button S.P.D.T. 10 Amps
9 1 18896 Handle Control
13 1 18897 Screw-Phil. Flat Hd. Mach. #8-32 X 1-1/4 (ZP)
14 2 02071 Screw
15 1 18895 Speed Control Handle
16 1 18675 Bracket Dead Man Handle Stop
18 2 02956 Locknut
23 4 08079 Screw, Shoulder Socket Hd. 5/16D X 1-1/2 (zinc-plated)
24 1 16075 Screw-Phil. Pan Hd. #8-32 X 1/2 (ZP)
25 1 18346 Terminal Block
31 2 18323 Screw
37 1 31028 Bracket-Control Panel Support
40 1 18364 Decal, Solution Control
41 1 18376 Decal, Squeegee Control
42 4 18385 Screw Cap
43 1 18402 Grip
44 1 18677 #8 - 32 x 1" Pan Head Screw
45 1 18657 Spacer
49 4 18660 5/16" Flat Washer
52 1 14827 Flasher Relay
53 1 15913 Clamp - Cable 1-1/8" Dia.
Item No. Qty. Part No. Description
