MACHINE PREPARATION
ATTACHING A CLEANING PAD TO YOUR PAD DRIVER - DISK HEAD
If using a oor pad with your pad driver:
1. Place your pad drivers on a work surface and remove the center lock tting from the pad driver. To do so,
squeeze the center lock wires inward and lift the center lock o the pads.
2. Connect the cleaning pad to the disk pad drivers by centering them on the drivers.
3. Squeeze center lock wires inward and press center lock down, tab side rst, compressing the pad and
then release the wires so that they lock in place holding the pad. Repeat for the other pad driver.
NOTE: The pad drivers are tufted pad drivers. Do not use a pad driver on the oor without a pad in place.
This will cause damage to your oor.
MACHINE PREPARATION
ATTACHING YOUR PAD DRIVER OR BRUSH TO THE SCRUBBER - DISK HEAD
The pad drivers or brushes are attached by using the automatic on/o system. This valuable ingenuity
removes the need for operators to kneel or strain to attach the pad driver or brush.
First, start by placing the pad driver or brush on the oor in front of the scrubber.
1. Turn the unit on using the power key switch.
2. Push or drive it into position so that the unit’s scrub head is centered over the pad driver(s) or brush(es).
3. Utilize the foot pedal to lower the scrub deck down onto the pad driver or brush by depressing the pedal
while shifting it to the right. Once clear of the lower notch, lifting your foot will lower the scrub deck. Make
sure that the shroud completely covers the pad driver(s) or brush(es) in the lowered position. Should
the shroud be resting on a portion of the pad driver or brush, the head isn’t centered and will not attach
properly.
4. The operation is completed by quickly pulsing the activation trigger. This will “click on” the pad driver(s)
or brush(es). If the pad driver(s) or brush(es) do not quickly engage, do not continue pressing the activation
trigger. Realign the scrub deck and try the procedure again. When you have the scrub deck aligned
properly, you should see a noticeable drop of the scrub deck when lowered and the bristle skirt on the
shroud should almost be touching the oor.
Close up showing center lock tab & wires
wires
tab
Squeeze center lock wires inward, press
down onto pad & release wires
Disconnect center lock tting & lay next
to the pad driver
Center pad on pad driver
1
2
3
Turn unit on using key switch
Position scrub head over pad driver(s)
or brush(es)
Lower the scrub head using the foot pedal
Quickly pulse the activation trigger
1 2 3
4
To Next Page
