3
This illustrated parts book covers:
CATALOG NO.
98190
SERIES
F
SIZE
22”
CAPACITY
20 Gal.
VOLTS
115V
AMPS
15
All specifications are subject to change without notice.
TABLE OF CONTENTS:
Safety Instructions 4
Preparation & General Precautions 6
Cleaning Tips 9
Machine Specifications 10
Operation Instructions 11
Maintenance Issues 13
Troubleshooting Table 15
Main Assembly 16
Upper Tank Assembly 17
Lower Tank Assembly 19
Control Panel Assembly 22
Brush Assembly 24
Pump Assembly 26
Recovery Dome Assembly 27
Wiring Diagrams 28
Tornado
®
Standard Warranty Program*
10 Years:
All plastic tanks and
rotationally-molded bodies
1) 5)
2 Years:
Parts on all Tornado and Tornado/Karcher
cleaning equipment
1)
2) 3) 5)
1 Year:
Labor on all Tornado and Tornado/Karcher
cleaning equipment
2) 5)
Warranties do not cover
components subject to normal
wear or abuse and misuse, and
have other limitations not specified
here. For full details , contact your
Authorized Tornado Distributor,
Service Center, or the Tornado
Technical Service Department.
Tornado sales and service
representatives are not
authorized to waive or alter the
terms of this warranty, or to
increase the obligations of
Tornado under the warranty.
1 Year:
Warranty on batteries and chargers,
one year pro-rated.
* Effective January 1
st
, 2004. Terms subject to change without notice.
1) Windshear™ Blower-Dryer, Insulation Blowers, T191, T201, CV 30, CV 38, CW 50, CW 100, Pro PAC Vacs,
Duo-Upright Carpetkeepers™, and all chargers are warranted for 1 (one) year for both parts and labor.
2) Warranties on all riding sweepers including the ICC1, KM 100/100 R, KMR 1250, and KMR 1700 are 24
months parts/6 months labor OR 1000 hours of operation, whichever comes first. Warranties on the
75/140 & 90/140 are 24 months parts/12 months’ labor OR 1,000 hours of operation whichever comes
first.
3) All-non wear item parts purchased after warranty expiration are warranted for 90 days.
4) Warranty starts from the date of sale to the consumer or, at Tornado’s discretion, 6 months after dealer
purchased the unit from Tornado, whichever comes first.
5) See separate limited 2-year pressure washer policy.
