tornos MULTIDECO 26/6 - 9.2.4 Cleaning; 9.2.5 Check

LOGBOOK − MULTIDECO
Chap. 9.2.5 / 15
300428 en − 03/07
EVERY 250 HOURS continied
What to do ? Remarks
9.2.4 Cleaning
− Clean:
− clamping collets,
− feeding collets,
− the interior of the spindles
and the suction filter of pumps including addition-
nal tank and filters.
To mount and dismount,
See instruction: OPERATION / MAINTENANCE
− Remove the guiding guards of the carriage guid-
ing no. 2 and 3
− Unscrew the 4 screw 1 of the guard A
then remove the swarf.
If necessary you may remove the guard B.
− ... on M
ULTIDECO 20/6, 20/8, 20/6b, 20/8b
and 32/6i
A
B
1
− Clean the fans
9.2.5 Check
− Check the operation of the fans. − Drawing: position 6
