G420587
1. Unhook the hood latch from the hood-lock
bracket.
G420588
2. Remove the 2 rivets and the hood-lock
bracket
from the hood.
G420589
3. While aligning the mounting holes, position the
CE lock bracket
and the hood-lock bracket
onto the hood.
Note: The lock bracket must be against the
hood.
Do not remove the bolt and nut assembly
from the lock-bracket arm.
4. Align the washers with the holes on the inside
of the hood.
5. Rivet the brackets and the washers to the hood.
G420590
6. Hook the latch onto the hood-lock bracket.
3466-702A Page 3–13 Setup: Installing the CE Hood Lock
