Note:Theadjustmentknobshavedetents
correspondingto0.022mm(0.0009inch)bedknife
movementforeachindexedposition.
3.Ifexcessivecontact/reeldragisevident,eitherbacklap,
refacethefrontofthebedknife,orgrindthecutting
unittoachievethesharpedgesneededforprecision
cutting;refertotheToroManualforSharpeningReeland
RotaryMowers(FormNo.09168SL).
Important:Lightcontactispreferredatalltimes.
Iflightcontactisnotmaintained,thebedknife/reel
edgeswillnotsufcientlyself-sharpenanddull
cuttingedgeswillresultafteraperiodofoperation.
Ifexcessivecontactismaintained,bedknife/reel
wearwillbeaccelerated,unevenwearcanresult,
andqualityofcutmaybeadverselyaffected.
Note:Asthereelbladescontinuetorunagainstthe
bedknife,aslightburrwillappearonthefrontcutting
edgesurfacealongthefulllengthofthebedknife.Ifa
leisoccasionallyrunacrossthefrontedgetoremove
thisburr,improvedcuttingcanbeobtained.
Afterextendedrunning,aridgewilleventuallydevelop
atbothendsofthebedknife.Thesenotchesmustbe
roundedofforledushwiththecuttingedgeofthe
bedknifetoensuresmoothoperation.
Note:Overtime,thechamfer(Figure23)willneed
tobegroundasitisonlydesignedtolast40%ofthe
bedknifelife.
g031270
Figure23
1.Lead-inchamferonright
endofbedknife
3.1.5mm(0.060inch)
2.6mm(0.25inch)
Note:Donotmakethelead-inchamfertoolargeas
itmaycauseturftufting.
