Toro 03721 - Servicing the Bedbar

g034114
Figure29
1.Angle-indicatormount
3.Bedknife
2.Edgeofthemagnetmated
withtheedgeofthe
bedknife
4.Angleindicator
4.Placetheangleindicatoronthemountasshownin
Figure29.
Note:Thisistheanglethatyourgrinderproduces;it
shouldbewithin2degreesoftherecommendedtop
grindangle.
ServicingtheBedbar
RemovingtheBedbar
1.Turnthebedbar-adjusterscrewscounterclockwiseto
backthebedknifeawayfromthereel(Figure30).
g016647
Figure30
1.Bedbar-adjustingscrew3.Bedbar
2.Spring-tensionnut
4.Washer
2.Backoutthespring-tensionnutuntilthewasherisno
longertensionedagainstthebedbar(Figure30).
3.Oneachsideofthemachine,loosenthelocknut
securingthebedbarbolt(Figure31).
g003334
Figure31
1.Bedbarbolt2.Locknut
4.Removeeachbedbarbolt,allowingthebedbartobe
pulleddownwardandremovedfrommachinebolt
(Figure31).
Note:Accountfor2nylonwashersand1stamped
steelwasheroneachendofthebedbar(Figure32).
g003335
Figure32
1.Bedbarbolt
3.Steelwasher
2.Nut4.Nylonwasher
AssemblingtheBedbar
1.Installthebedbar,positioningthemountingears
betweenthewasherandthebedbaradjuster.
2.Securethebedbartoeachsideplatewiththebedbar
bolts(nutsonbolts)and6washers.
Note:Positionanylonwasheroneachsideofthe
side-plateboss.Placeasteelwasheroutsideeachofthe
nylonwashers(Figure32).
3.Torquethebedbarboltsto37to45N∙m(27to33
ft-lb).
Note:Tightenthelocknutsuntiltheoutsidesteel
washerstopsrotatingandendplayisremoved,butdo
notovertightenordeectthesideplates.Thewashers
ontheinsidemayhaveagap.
4.Tightenthespring-tensionnutuntilthespringis
collapsed,thenbackoff1/2turn(Figure33).
