ProductOverview
Specications
CuttingUnit
Weight
27inch,8blade
66kg(145lb)
27inch,11blade
68kg(150lb)
32inch,8blade
74kg(162lb)
Attachments/Accessories
AselectionofToro-approvedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww.Toro.comforalistofallapproved
attachmentsandaccessories
Tobestprotectyourinvestmentandmaintainoptimal
performanceofyourToroequipment,countonTorogenuine
parts.Whenitcomestoreliability,Torodeliversreplacement
partsdesignedtotheexactengineeringspecicationofour
equipment.Forpeaceofmind,insistonTorogenuineparts.
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
MakingAdjustments
AdjustingtheBedknifetotheReel
Usethisproceduretosetthebedknifetothereelandtocheck
theconditionofthereelandbedknifeandtheirinteraction.
Aftercompletingthisprocedure,alwaystestthecutting
unitperformanceunderyoureldconditions.Youmay
needtomakefurtheradjustmentstoobtainoptimalcutting
performance.
Important:Donotovertightenthebedknifetothereel
oryouwilldamageit.
•Afterbacklappingthecuttingunitorgrindingthereel,you
mayneedtomowwiththecuttingunitforafewminutes
andthenperformthisproceduretoadjustthebedknifeto
thereelasthereelandbedknifeadjusttoeachother.
•Youmayneedadditionaladjustmentsiftheturfis
extremelydenseoryourcuttingheightisverylow.
Youwillneedthefollowingtoolstocompletethisprocedure:
•Shim0.0508mm(0.002inch)—ToroPartNo.125-5611
•Cuttingperformancepaper—ToroPartNo.125-5610
1.Turnthebedbar-adjustingscrewscounterclockwise
toensurethatthebedbardoesnotcontactthereel
(Figure11).
g000486
Figure11
1.Bedbar-adjustingscrew
2.Tipthecuttingunittoexposethebedknifeandthereel.
Important:Ensurethatthenutsonthebackend
ofthebedbar-adjustingscrewsarenotrestingon
theworksurface;usethekickstand(Figure12).
