Toro 03731 - Installing the O-Ring and the Grease Fitting

3
InstallingtheO-ringand
theGreaseFitting
Partsneededforthisprocedure:
1
O-ring
1
Greasetting
Procedure
Thegreasettingmustbeinstalledonthereelmotor
sideoftheverticutter.Usethefollowingdiagramto
determinethepositionofeachreelmotor(Figure4).
g031275
Figure4
1.Verticutter15.Verticutter5
2.Verticutter26.Reelmotor
3.Verticutter37.Weight
4.Verticutter4
1.Removeanddiscardthesetscrewonthe
reel-motorsideplate(Figure5).
g028407
Figure5
1.Bolts
3.Setscrew(removeand
discard)
2.Straightgreasetting
(install)
2.Installthestraightgreasetting(Figure5).
3.Forverticutter2andverticutter4locations
(Figure4),movetheendweighttotheopposite
sideofthecuttingunit.
4.Iftherearenoboltsonthereel-motorsideplate,
installthem(Figure5).
5.InstalltheO-ringonthereelmotor(Figure6).
g191072
Figure6
1.O-ring
